TOMAHAWK™
SLIM DIAMETER .204 ID (5.2mm)
HUNTING SHAFT
Tomahawk™ shafts offer tack-driving accuracy when paired with a quality broadhead. Tight tolerances of straightness, weight and spine across every 12-pack make the Tomahawk™ a class leader.
The slim diameter shaft offers less drag for flatter trajectory and the strength of the 100% carbon wall provides excellent durability and target penetration.
Fine-tune the FOC of the Tomahawk™ with the optional stainless steel Half-out or the ZT two-piece Outsert.
HALF-OUT .204
2 sizes
WEIGHT
55 grains
SIZE
SIZES 1 & 2
Build arrows with optimum FOC and increased durability with the .204 Half-Out. The 55 grain stainless steel half-out will out-perform any aluminium half-out. For Tomahawk shafts, SIZE 1 fits 250-275-300 spine, SIZE 2 fits 350-400 spine. Material: Stainless Steel
SPECIFICATIONS
STRAIGHTNESS | WEIGHT TOLERANCE | AMO LENGTH |
---|---|---|
+/- .003 or better |
+/- 1.5 grains | 32.75 |
SPINE | GPI | OD |
250 | 10.9 | 0.2790 |
275 | 10.4 | 0.2760 |
300 | 10 | 0.2725 |
350 | 8.7 | 0.2660 |
400 | 8.2 |
0.2615 |
